CODECASA 50 – HULL C107 – M.Y. LADY ANN MAGEE


DATA SHEET

Year2001
Length overall49.90 metres
Maximum beam9.50 metres
Maximum draught3.30 metres
HullHigh-tensile Steel AH 36
SuperstructureAluminium 5083 H111/H321
ClassificationLloyd’s Register ✠ 100 A1 SSC “YACHT” Mono G6 ✠ LMC Full MCA COMPLIANT – Commercial Service
Displacement480 tonnes
Main engines2 Caterpillar 3516B (2200 HP @ 1600 rpm)
Generators2 Northern Lights of 125 Kw each
Emergency generator 1 Northern Lights of 50 Kw.
Propellers2 Finnscrew 5-blade Class S
Maximum speed18.00 knots
Range4600 miles @ 14 knots
Fuel capacity120,000 litres
Fresh water capacity19,000 litres
Guest cabins1 Owner’s Suite
3 Double Cabins
2 Twin Cabins (with 1 extra pull-down bed)
Crew cabins1 Captain’s Cabin
1 Chief Engineer’s Cabin
4 Twin Cabins
